Wire Rope Handle Hoist for Lifting and Pulling on Power Line Projects
The wire rope handle hoist is a manual lever hoist for lifting and pulling loads on power line projects. A ratchet lever and forged gear train let the operator raise, hold and lower a load in controlled steps, while an automatic brake keeps it in place when the handle is released. Four models cover rated lifting and pulling from 8KN to 54KN, with a standard 20m steel rope and net weights from 6.8kg to 52kg.
Design and Operation
- Manual ratchet lever: controlled raising, holding and lowering.
- Forged alloy steel gears: built for repeated lifting under load.
- High-tensile steel rope: supplied with a standard 20m length.
- Automatic brake system: holds the load when the handle is released.
- Overload protection device: guards against over-tension.
- Zinc-plated finish: corrosion protection for outdoor work.
- Ergonomic handle: keeps hand effort within the rated range.
Technical Specifications
| Item No. |
Model |
Rated Lifting / Pulling (KN) |
Once Journey (mm) |
Rope Diameter (mm) |
Standard Rope Length (m) |
Net Weight (kg) |
Hand Force at Rated Load (N) |
| 14183 |
HSS408 |
8 / 12.5 |
40 |
8.3 |
20 |
6.8 |
343 |
| 14184 |
HSS416 |
16 / 25 |
40 |
11 |
20 |
13 |
400 |
| 14185 |
HSS432 |
32 / 50 |
16 |
16 |
20 |
25 |
441 |
| 14186 |
HSS454 |
54 |
20 |
20 |
20 |
52 |
550 |
Quality Control and Testing
Gears, frames and rope are assembled and checked for ratchet operation, brake hold and overload-device function before packing. Each batch is inspected against its stated rated load. Products are manufactured under ISO 9001 certified quality management, and an inspection record is supplied with every shipment.
Typical Applications
- Transmission tower component lifting
- Substation equipment installation
- Temporary cable support systems
- Emergency repair operations
Handling and Care
- Before use: inspect the rope, hook and brake, and confirm the load is within rating.
- In use: keep the load steady and watch for rope damage.
- After use: clean and lubricate the moving parts and store dry.
Factory Support and Buyer Assurance
- Manufacturer-direct pricing with no trading-layer mark-up
- OEM and ODM available with custom configurations and branding
- Model selection support (HSS408 to HSS454) based on load and rope length
- Replaceable wear parts available
- 12-month limited warranty
Tell us your load, lift height and working conditions, and our engineers will confirm the right HSS model and a factory-direct quotation within one working day.
