Vertical Cable Reel Stand for Space-Saving Storage and Smooth Cable Deployment
The Vertical Cable Reel Stand holds and pays out cable on edge rather than on a horizontal axle, so a reel that would occupy a wide bay on a cradle stands in a fraction of the floor area. Five models cover reel diameters from 500mm to 1500mm and rated loads from 10KN to 70KN, letting power plants, substations and cable stores keep more reels accessible within the same footprint.
Why Vertical Works on Site
- Upright footprint: frees floor space in busy substations and cable stores where horizontal cradles are impractical.
- Reinforced steel frame: support arms hold the reel steady while it rotates for deployment.
- Cable protection: rounded contact surfaces and deburred edges protect cable jackets during payout.
- Locking mechanism and stable base: prevent accidental rotation and tipping on uneven floors.
- Quick reel loading: smaller models can be mounted and swapped without a crane.
- Easy rotation: a single operator can turn the reel for controlled, orderly deployment.
Technical Specifications
| Item No. |
Model |
Reel Diameter (mm) |
Rated Load (KN) |
Weight (kg) |
| 15131 |
SIW-1 |
500 |
10 |
36 |
| 15132 |
SIW-3A |
800 |
30 |
44 |
| 15133 |
SIW-3B |
1000 |
30 |
55 |
| 15133A |
SIW-5A |
1200 |
50 |
100 |
| 15135 |
SIW-7A |
1500 |
70 |
170 |
Quality Control and Testing
Frames are fabricated from steel tube and plate, welded under a documented procedure, checked for squareness on a jig, and coated against corrosion before packing. Every surface that touches the cable is deburred and smoothed, and each stand is inspected before shipment. Production runs under ISO 9001 certified quality management.
Typical Applications
- Power plant cable management
- Substation wiring projects
- Temporary power installations
- Cable storage yards and warehouses
Factory Support and Buyer Assurance
- Manufacturer-direct pricing with no trading-layer mark-up
- OEM and ODM available with custom sizes, colours and branding
- Model selection support (SIW-1 to SIW-7A) based on reel diameter and load
- Spare support arms, bearings and locking parts held in stock
- 12-month limited warranty
Tell us your reel diameter and required load, and our engineers will recommend the right SIW model and confirm a factory-direct quotation within one working day.
